AS0607

AS0607

Most durable and reliable scissor stacks

Lift Capacity
230 kg
Working Height
7.80 m

Product Information

  • Most durable and reliable scissor stacks
  • Reinforced working platform
  • Advanced charger with voltage protection
  • Higher driver comfort and security

Specifications



Lift Capacity 230 kg
Extension Lift Capacity 120 kg
Platform Occupants 2
Working Height 7.80 m
Platform Height 5.80 m
Length 1.83 m
Width 0.76 m
Height 2.10 m
Height – Rails Folded 1.71 m
Platform Dimension (L x W) 1.63 x 0.74 m
Length – Platform Extension 0.90 m
Min. Ground Clearance – Stowed 0.06 m
Min. Ground Clearance – Raised 0.02 m
Wheelbase 1.32 m
Turning Radius – Outside 1.55 m
Max. Gradeability 25 %
Max. Slope 1,5/3,0 °
Up/Down Speed 16/34 sec
Driving Speed 0,8 – 4,0 km/h
Non-marking Tires 305 x 115 mm
Driving Motor Hydraulic
Lifting Motor 24V/3,3kW
Battery 4x6V/225Ah
Charger 24V/30A
Machine Weight 1.560 kg
